EWP-WX1810H-PWR

EWP-WX1810H-PWR

Regular price $2,400.00 USD
Regular price Sale price $2,400.00 USD
Sale Sold out

Product Feature

  • All-in-one Gateway, All Inclusive AP License
  • 802.11ac AP Management, H3C Oasis Wireless Cloud Platform Management
  • Carrier-Class Wireless User Access Control and Management
  • Intelligent Channel Switching, Intelligent AP Load Sharing, Flexible Forwarding Modes
  • Layer 7 Wireless Intrusion Detection and Prevention Systems (wIDS / wIPS)
  • Embedded PoE+ Capability
  • Layered AC Architecture
  • RealTime Spectrum Guard

    [qiege]

    Product Overview

    The H3C WX1800H wireless Access Controller (AC) is well designed and positioned for SME network. It features gateway and AC function integration, reducing the number of devices and TCO in network. It adopts the innovative Comware V7 platform (referred to as V7 hereafter). V7 comes with the standard granular user control management, comprehensive RF resource management, 7x24 wireless security control, fast layer-2 and layer-3 roaming, strong QoS and IPv4/IPv6 dual stack. V7 adds in various novel wireless technologies such as multi-core control plane, Bonjour and Hotspot 2.0. It also supports multiple network configurations such as cloud management and layered AC.


    Click Here to Download Datasheet

    Hardware Specifications

    Item

    WX1804H-PWR

    WX1810H-PWR

    WX1820H

    Dimensions (WxDxH)

    220*145.5*27mm

    440*260*43.6mm

    220*145*22mm

    Weight

    0.6kg

    3.6kg

    0.95kg

    Wireless throughput

    500Mbps

    800Mbps

    800Mbps

    Port

    WAN 1*GE + LAN 4*GE(PoE+) + 1*USB

    WAN 2*GE + LAN 10*GE (PoE+) + 1*USB

    WAN 1*GE + LAN 4*GE + 1*USB+ 1*SD Card slot

    Power supplies

    100V AC~240V AC;50/60Hz

    Operating and storage

    temperature

    0°C~40°C/-40°C~70°C

    Operating and storage relative humidity

    5%~95%

    Safety compliance

    UL 60950-1

    CAN/CSA C22.2 No 60950-1

    IEC 60950-1

    EN 60950-1/A11

    AS/NZS 60950

    EN 60825-1

    EN 60825-2

    EN60601-1-2

    FDA 21 CFR Subchapter J

    EMC

    ETSI EN 300 386 V1.3.3:2005

    EN 55024: 1998+ A1: 2001 + A2: 2003

    EN 55022 :2006

    VCCI V-3:2007

    ICES-003:2004

    EN 61000-3-2:2000+A1:2001+A2:2005

    EN 61000-3-3:1995+A1:2001+A2:2005

    AS/NZS CISPR 22:2004

    FCC PART 15:2005

    GB 9254:1998

    GB/T 17618:1998

    MTBF

    ≥154 years
