S5720-EI Series Switch S5720-36C-EI-AC S5720-36C-PWR-EI-AC S5720-32X-EI-AC

SKU S5720-36C-EI-AC


  • Products Status: Stock
  • Model Number: S5720-36C-EI-AC
  • Condition: New
  • Warranty: 1 Year
  • Place of Origin: China (Mainland)

  • Description
  • Reviews
  •  Overview

    S5720-36C-EI-AC  Huawei 5700 series 28 port gigabit 4 port 10g switch

    Product Code


    Fixed Ports

    28 x 10/100/1,000 Base-T (4 GE Combo SFP)

    4 x 10 Gig SFP+

    Extended Slots

    One extended slot

    Memory (RAM)

    2 GB


    340 MB

    MAC Address Table Size Forwarding Performance

    64 MAC

    Forwarding Performance

    132 Mpps

    Switching Capacity

    598 Gbit/s

    Power Supply

    AC power supply


    Not Supported

    Voltage Required


    Rated voltage range: 100V to 240V AC, 50/60 Hz

    Maximum voltage range: 90V to 264V AC, 47 Hz/63 Hz

    Front Power Input

    No No

    Typical Power Consumption


    Dimensions (W x D x H)

    442 mm x 420 mm x 44.4 mm


    9.76 kg



    Product Model

    S5720-P-EI S5720-X-EI S5720-PC-EI S5720-C-EI
    Switching Capacity 598 Gbit/s 598 Gbit/s 598 Gbit/s 598 Gbit/s
    Forwarding Performance S5720-32P-EI-AC: 48 Mpps
    S5720-52P-EI-AC: 78 Mpps
    S5720-32X-EI-AC: 102 Mpps
    S5720-32X-EI-24S-AC: 102 Mpps
    S5720-32X-EI-24S-DC: 102 Mpps
    S5720-50X-EI-AC: 129 Mpps
    S5720-50X-EI-DC: 129 Mpps
    S5720-50X-EI-46S-AC: 129 Mpps
    S5720-50X-EI-46S-DC: 129 Mpps
    S5720-52X-EI-AC: 132 Mpps
    S5720-36PC-EI-AC: 78 Mpps
    S5720-56PC-EI-AC: 108 Mpps
    S5720-36C-EI-28S-AC: 132 Mpps
    S5720-36C-EI-28S-DC: 132 Mpps
    S5720-36C-EI-AC: 132 Mpps
    S5720-36C-PWR-EI-AC: 132 Mpps
    S5720-56C-EI-48S-AC: 162 Mpps
    S5720-56C-EI-48S-DC: 162 Mpps
    S5720-56C-EI-AC: 162 Mpps
    S5720-56C-EI-DC: 162 Mpps
    S5720-56C-PWR-EI-AC: 162 Mpps
    S5720-56C-PWR-EI-DC: 162 Mpps
    S5720-56C-PWR-EI-AC1: 162 Mpps
    Extended Slots N/A One expansion slot supporting the following functions:
    • 2-port 10 GE SFP+ optical interface card
    • 2-port QSFP+ dedicated stack interface card
    MAC Address Table 64k MAC address entries
    MAC address learning and aging
    Static, dynamic, and black hole MAC address entries
    Packet filtering based on source MAC addresses
    VLAN Features 4,094 VLANs
    Guest VLAN, Voice VLAN
    VLAN assignment based on 4,094 VLANs
    Guest VLAN and voice VLAN
    VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
    1:1 and N:1 VLAN mapping
    VLAN-based transparent transmission of protocol packets MAC addresses, protocols, IP subnets, policies, and ports
    VLAN mapping
    IP Routing Static routes, RIPv1/v2, and RIPng
    OSPF, OSPFv3, IS-IS, and IS-ISv6
    BGP, BGP4+, ECMP, and routing policy
    Interoperability VLAN-Based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST)
    Link-type Negotiation Protocol (LNP) (similar to DTP)
    VLAN Central Management Protocol (VCMP) (similar to VTP)
